A resilient and malleable metal for tailored creations
Experience the Blend of Strength and Malleability in Copper, Allowing Tailored Product Creations. Discover the Wide-ranging Applications of Copper Sheets in Industries and Mechanical Ventures. Select from our range of Copper Sheets, Available in Different Sizes, Grades, and Widths, designed to fulfil client specifications.
Applications
- Telecom connectors
- Heat exchangers
- Boilers
- Gaskets
- Electrical components
Size
THICKNESS: 0.10MM TO 10MM
SIZE: 14-INCH X 48-INCH
16-INCH X 48-INCH
24-INCH X 48-INCH
48-INCH X 48-INCH
HARDNESS: SOFT, QUARTER HARD, HALF HARD, 3/4 HARD, HARD, EXTRA HARD AND SPRING HARD
| Products | Application |
| Copper Strips: Electrolytic high conductivity copper |
Screening of XLPE cables |
| Electrolytic tough pitch | Electrical components, Bus bars, Commutators, Process equipment & radiators |
| Silver bearing | Electrical components, Radiators & Brazing |
| Phosphorus deoxidised non-arsenical | Tubing, Chemical engineering & general applications especially those involving welding & brazing |
| Tin bearing & DHP | Radiators & Heat exchangers |
| Chemical Composition of copper | ||||
| Material | Normal composition |
Nearest relevant composition specification |
||
|
BS:2870 |
ISO |
JIS |
||
| Electrolytic tough pitch H.C. Copper | Cu – 99.90% Min. Pb – 0.005% Max Bi – 0.001% Max O2 – 0.060% Max |
C 101 |
CuETP |
H3100 |
| Phosphorous deoxidized copper (DONA) | Cu – 99.85% Min P – 0.013-0.050% |
C106 |
CuDHP |
H3100 |
| * Material confirming to other National Specification e.g. ASTM, DIN etc. is also provided. * Available in Strips, Sheets, Plates & Circles form. |
||||
| Copper Specification as per: B.S. :2870 | ||||||
| Electrolytic tough pitch H.C. copper |
‘O’ |
210 Min 210 Min 240 Min 290 Min |
35 Min 35 Min 10 Min – |
55 Max 65 Max 70 to 95 90 Min |
Cu ETP ISO: 1337 |
H 3100 C 1100 |
| Phosphorous deoxidized Copper |
‘O’ |
210 Min 210 Min 240 Min 290 Min |
35 Min 35 Min 10 Min – |
55 Max 65 Max 70 to 95 90 Min |
Cu DHP ISO: 1337 |
H 3100 C 1220 |
| ‘O’ | : Annealed condition |
| ½ H | : Half hard |
| H | : Hard |
| * | : Electric conductivity at 20 Deg. Cel. 100% IACS (For Cu ETP ‘O’ Temper) |
